400 lbs Specs:
600 lbs Specs:
The Auxx-Lift is the ideal storage solution to keep your garage organized. It is the largest and strongest platform on the market with 4' x 8' area and max. 600 lbs lifting capacity.
Wirelessly controlled
The Auxx-Lift comes with an easy to use wireless remote control allowing you to lower/raise your platform from safe distance.
Programmable stopping points allow you to set high and low point parameters, prevent your items hitting the ceiling or floor.
-
Auto-Stop
Lift will automatically stop in scenarios where remote control loses connection or runs out of battery.
-
Active-Press
Button to lower platform needs to be continuously pressed to avoid accidental damage or injury.
Industry Leading Safety Features
-
No heavy lifting
Eliminate the safety hazard of reaching up to grab heavy items. Per OSHA, fall from Ladder is a major source of injury both on and off the job. A fall from any height – even one or two feet – could cause serious injuries such as bone fractures and head injuries.
-
Self-leveling Platform
Differential motor technology automatically adjust the weight distribution throughout to keep platform nearly level even with heavy asymmetrically loading. The controller monitors weight on the platform and will prevent you from lifting/lowering items.
- Tested to UL-Standards
Auxx-Lift is the only lift that has been tested to the highest UL-Standard requirements with all components having a minimum Factor of Safety of 4x allowing you to lower/raise your platform from safe distance.
Most versatile garage storage solution
Customization to fit your garage storage needs
The Auxx-Lift comes in various sizes, colors, and lifting capacities with one resolute goal. Improve your garage organization.
Platform sizes
Lifting Capacities
Finishes
NOTE: Pearl-White and Stainless-Steel finish is not available for all platform sizes.
For 400lbs:
General specs
- Model:Auxx-Lift 1400
- Lifting Capacity:Up to 400 lbs
- Max. Travel Distance1:16 ft
- Min. stored height2:8 in
Roof Support
- Type:(2) 1 5/8" x 60" strut channel
- Fasteners:(8) 5/16" x 4" SPAX© Lag Bolts
- Mounting Area:5' x 5' over 3 joists/rafters
- Cable:1/8” Vinyl-coated Steel 7x19
- Cable Strength3:2,000 lbs
Operating Requirements
- Switch Voltage:110V / 120V
- Transmitter:433.92 MHz
- Electrical Cord:10 FT / 16 gauge / NEMA 5-15
- Min. circuit size:15 amp
Platform Specs
- Thickness:2.5 inches
- Support Frame:C-Channels (15gauge)
- Face material:3 x 3 galv. Wire Mesh (4gauge)
Motors
- Type:IP44 (T-Motor)
- Rated Power:235 W
- Rated Current:2.2 A
- Voltage / Phase:100-120V AC / Single
- Duty Cycle @ Max. Capacity:3 min on, 15 min off4
Size and Weight
- Dimensions:3ft x 6ft, 3ft x 8ft, 4ft x 6ft, 4ft x 8ft
- Weight:128 pounds
Available Finishes
What's in the box
- 2 Motors
- Controller
- Remote Control
- 2 C-Strut Channels
- Platform
- Mounting Hardware
We offer multiple cable length versions. E.g. The 400 lbs version can be equipped with a cable length to allow 16 ft of travel.
The distance measured from your ceiling to the bottom of the platform when in raised position.
Ultimate tensile strength
If you run the Auxx-Lift continuously for more than 3 min at a time, the motors will switch off automatically and require to cool down for 15 min or less.
For 600lbs:
General specs
- Model:Auxx-Lift 1600
- Lifting Capacity:Up to 600 lbs
- Max. Travel Distance1:22 ft
- Min. stored height2:8 in
Roof Support
- Type:(2) 1 5/8" x 60" strut channel
- Fasteners:(8) 5/16" x 4" SPAX© Lag Bolts
- Mounting Area:5' x 5' over 3 joists/rafters
- Cable:3/16” Vinyl-coated Steel 7x19
- Cable Strength3:4,200 lbs
Operating Requirements
- Switch Voltage:110V / 120V
- Transmitter:433.92 MHz
- Electrical Cord:10 FT / 16 gauge / NEMA 5-15
- Min. circuit size:15 amp
Platform Specs
- Thickness:2.5 inches
- Support Frame:C-Channels (15gauge)
- Face material:3 x 3 galv. Wire Mesh (4gauge)
Motors
- Type:IP44 (T-Motor)
- Rated Power:680 W
- Rated Current:6.0 A
- Voltage / Phase:100-120V AC / Single
- Duty Cycle @ Max. Capacity:3 min on, 15 min off4
Size and Weight
- Dimensions:3ft x 6ft, 3ft x 8ft, 4ft x 6ft, 4ft x 8ft
- Weight:128 pounds
Available Finishes
What's in the box
- 2 Motors
- Controller
- Remote Control
- 2 C-Strut Channels
- Platform
- Mounting Hardware
We offer multiple cable length versions. E.g. The 400 lbs version can be equiped with a cable length to allow 16 ft of travel.
The distance measured from your ceiling to the bottom of the platform when in raised position.
Ultimate tensile strength
If you run the Auxx-Lift continously for more than 3 min at a time, the motors will switch off automatically and require to cool down for 15 min or less.
